YJ-R505 is a mixed type (DCI) composite amino alcohols of organic inhibitor, by alcohol amine to many different types of inorganic group has certain rust of compound and into, does not contain nitrite. Join YJ-R505 to concrete, different groups of inhibitors of membrane, membrane can adsorb and oxide film formed on the steel surface, to blockade the harmful substances and steel surface contact, prevent or delay the corrosion occurred; at the same time, YJ-R505 has the effect of reducing the water, can effectively improve the performance of concrete mixture and impermeability of concrete increases, reduce the diffusion rate of dissolved oxygen and diffusion coefficient of chloride ions. The comprehensive function of the two, and finally improve the durability of the concrete structure, extend the service life of concrete structure to.

適用范圍：

Scope of application:

1、水工建筑（大壩、橋梁隧道等）、海工建筑（護堤、碼頭等）、地下設施（地鐵、地下停車場）、建筑物基礎以及混凝土結構的加固與修補。

1, hydraulic structures (dam, bridge and tunnel etc.), marine structures (berm, dock etc.), underground facilities (subway, underground parking lot), building foundation and concrete structure strengthening and repairing.

2、各類工業污水池、水塔、貯罐、糧倉、油罐、山洞內存貯庫等。

2, all kinds of industrial sewage pool, water tower, storage tank, tank, granary, cave of memory storage.

3、使用海砂建筑、使用化冰鹽的結構。

3, the use of sea sand building, use of deicing salt structure.

4、公路、鐵路等預應力結構以及其他重要的建筑。

4, highway, Railway Prestressed Structure and other important buildings.

阻銹性能

Rust inhibiting properties

項目 標準指標 YJ-R505檢測指標

Project standard YJ-R505 detection index

鹽水浸漬試驗 電位 0～-250 mv 電位 0～-200 mv

Salt water immersion test potential of 0 ~ -250 MV potential of 0 ~ -200 MV

混凝土浸烘試驗（相對于不摻阻銹劑） 銹蝕面積減少 95%以上 銹蝕面積減少 98%以上

Leaching and drying experiment of concrete (relative to the non doped rust corrosion area) is less than 95% corrosion area is less than 98%

混凝土性能

The performance of concrete

項目 標準指標 摻 YJ-R505鋼筋阻銹劑混凝土性能

Project standard YJ-R505 doped reinforced concrete corrosion inhibitor performance

抗壓強度比，% >90 100～120

Compressive strength ratio,% >90 100 ~ 120

凝結時間差，min -120～+120 -60～+120

Condensation time difference, min -120 to +120 -60 to +120

抗?jié)B性 不降低 不降低

Impermeability not reduced without decreasing the

推薦摻量

Recommended dosage

環境類型 單方混凝土摻量（kg/m3）

Environment type unilateral concrete admixture (kg/m3)

輕度腐蝕環境 一般建筑、地下工程、預應力孔道、預應力結構 8～10

Mildly corrosive environment building, underground engineering, prestress, prestressed structure is 8 ~ 10

重度腐蝕環境 海洋海港工程的水位變動區和浪濺區結構、橋梁、氯離子含量大于 5000 mg/L的鹽堿地地區、污水處 理池結構 10～16

Severe corrosive environment of Marine Harbour Engineering fluctuating water level zone and splash zone structure, bridge, chloride ion content of more than 5000 mg/L of saline alkali land area, the sewage treatment pool structure of 10 ~ 16

施工注意事項

The matters needing attention in the construction

1、YJ-R505略有減水作用，可在保持原流動度的情況下適當減水。

1, YJ-R505 slightly decrease water effect, can maintain the original flow conditions appropriate to reduce water.

2、本品適應于通用水泥、特種水泥和粉煤灰、礦渣粉及硅灰等礦物摻合料，與常用減水劑有較好的相容性。

2, this product is suitable for general cement, special cement and fly ash, slag and silica fume admixture, and common water reducing agent has good compatibility.

3、加入本品的混凝土工程，必須事先做配合比試驗。

3, to join the concrete project of this product, must first do mix ratio test.

4、在高質量混凝土中才能更有效地發揮作用，必須遵守相關規范和設計規定，確?；炷临|(zhì)量與密實性。

4, the high quality of concrete can be more effectively play a role, must comply with the relevant standards and design regulations, to ensure the concrete quality and compactness.

5、本品為液體，50 kg或 200 kg桶裝，需密封、避光、陰涼處保存，儲存期六個月。

5, the product is liquid, 50 kg or 200 kg barreled, sealing, avoid light, preserved in cool and dry place, storage period of six months.

YJ-R505復合氨基醇類混凝土鋼筋阻銹劑阻銹性能試驗

Composite amino alcohols concrete reinforcement rust inhibitor rust performance test of YJ-R505

YJ-R505復合氨基醇類阻銹性能試驗研究包括鹽水浸漬試驗與混凝土浸烘試驗，具體試驗方法參照YB/T9231《鋼筋阻銹劑使用技術規程》進行。

Experimental study on Corrosion Properties of YJ-R505 composite amino alcohols resistance including drying immersion test salt solution immersion test and concrete, specific test method according to YB/T9231 "rebar inhibitor use of technical regulations".

備注：

Remarks.

1、鹽水浸漬實驗：添加YJ-R505的氯化鈉溶液，鋼筋光潔如新，未出現任何銹斑，阻銹效果顯著。

1, salt solution immersion test: Sodium Chloride Solution add YJ-R505, reinforced bright, no rust, rust effect.

2、海工耐久混凝土原材料要求：

2, marine durable concrete raw materials:

1、Po. 42.5 硅酸鹽水泥

1, Po. 42.5 Portland cement

2、粉煤灰、礦渣、微硅粉等摻合料

2, fly ash, slag, silica fume and other admixtures

3、最大粒徑不超過25 mm的非活性集料

3, the maximum size of not more than 25 mm of non active aggregate

4、不得使用海砂和人工砂

4, do not use sand and artificial sand

5、減水率至少達25%的高效外加劑，混凝土中應加入適量復合氨基醇類混凝土鋼筋阻銹劑原材料中限制氯離子含量。

5, high rate of water reducing admixture of at least 25%, should limit the content of chlorine ion by adding proper amount of composite amino alcohols concrete reinforcement rust inhibitor in raw material of concrete.

3、使用說明

3, instructions for use

1、YJ-R505摻入混凝土中，阻止或延緩鋼筋銹蝕，在國際分類中，屬于“摻入型”（DCI）。

In 1, YJ-R505 in concrete mixing, prevent or delay the corrosion of reinforcement, in international classification, belongs to the "mixed" type (DCI).

2、將YJ-R505與計量水、水泥、集料同時加入混凝土攪拌機中，適當延長攪拌時間，確保攪拌均勻。

2, the YJ-R505 and the measurement of water, cement, aggregate simultaneously to join the concrete mixer, prolong mixing time, ensure uniform mixing.

3、YJ-R505與其它外加劑復合使用時，應先做混凝土試配，以確定其適應性；配制混凝土所用原料應符合《建筑用卵石、碎石》GB/T14685和《建筑用砂》GB/T14684。

3, YJ-R505 and other admixture compound use, should do first concrete test, to determine their adaptability; the raw materials shall be in accordance with the "building of pebble, gravel and sand for building" GB/T14685 "" GB/T14684 concrete.

4、YJ-R505粉劑如有輕微吸潮結塊可溶于水中使用，液劑產品表面可能會有泡沫，不影響使用。在運輸、儲存過程中應避免雨淋、受潮，陰涼通風保存，遠離易燃易爆物，嚴禁明火。

4, YJ-R505 powder as a slight hygroscopic agglomerate soluble in water use, surface liquid products may have a bubble, does not affect the use. In the process of transportation, storage should avoid drench, damp, cool ventilated preservation, away from flammable and explosive materials, is strictly prohibited fire.

5、操作人員宜佩帶口罩、橡皮手套等必要防護措施。廢液、廢粉不得隨意傾倒

5, the operator should wear masks, rubber gloves and other necessary protective measures. Waste water, waste powder shall not arbitrarily dumping
